In consideration of environmental relief and energy saving Franklin Electric developed a High Efficiency 6″ Submersible Borehole System, consisting of a synchronous submersible NEMA motor associated variable frequency drive and output filter.
System Product Advantages:
- One-stop shop – perfectly matching components guarantee first-class performance
- Up to 20 % energy saving*
- System payback < 2 years
- Up to 13 % improved motor efficiency (system up to 11 %) with excellent partial load behavior*
- SKU reduction
- Significant lower motor heat rise
- Increased lifetime
- Higher power density*
- Lightweight
- Easy set-up due to tailored pre-setting, user interface and Franklin Electric engineered software
- Speed control
- Optimum aggregate operation – pump matches system any time
- Incorporated soft start and protection features
- Increased lifetime
- No additonal investment
- Reduced Amps
- Smaller drop lead cross size
- Top class protection with electronics in IP66/54**
- Easy retrofit – no additional cabinet cost
- Power factor corrected input
- No power compensation needed
- Communication Modbus (RS485 and Ethernet)
System Technical Specification:
- Power Supply:
- Voltage 400 V ± 10 %
- Frequency 50 Hz ± 6 %
System Options:
- Power Supply: 200 V & 500 V
- PT100 protection
- Motors in 316SS and 904L
- Plug-in card 6x DI/DO – 308 170 201
- Plug-in card – 1x AI & 2x AO 308 170 206
- Plug-in card PT100 – 308 170 202
- Plug-in card Profibus – 308 170 203
- Sinus output filters in IP54 and IP00*In comparison to current asynchronous technology
**Alternative electronics in IP21/00 for cabinet assembly available
